Ubiqiti Device Bridge Switch UDB-SWITCH [PC]

Name: Ubiqiti Device Bridge Switch UDB-SWITCH [PC]
Brand: Ubiquiti
SKU: 35954
Price: 656.00 AUD
Availability: OutOfStock

$656.00 AUD

GST included Shipping calculated at checkout.

Out of stock

Price match

Order in H, M, Seconds (before 1pm Sydney time) for same day despatch.

Fast dispatch from Somersby, NSW Easy returns Australian warranty & local support

Pickup availability

1/80 Somersby falls RD, Somersby NSW

Unavailable for pickup

Product details

SKU: 35954

Categories: Computers Coming Soon, PC Switches & Wifi, Phaser Computers, Ubiquiti Networking

Tags: Network, wifi

Why buy from Phaser FPV?

Dependable — Phaser started in 2014. Long reputable history and 5 star reviews.
Speed — All stock is in our retail store in Somersby NSW Australia. We ship express today; you often receive tomorrow. Shipping details.
Transparent stock — If it says in stock, we ship today. If we know the ETA, we show it on the product.
Experience — Across our staff you'll find people who fly, build, and use this gear. Not sure what to buy? Call us — we'll help you avoid buying twice.
Free gift on first and recurring orders
Active on social media — tag us or DM us
Large Facebook community for like-minded pilots
GST registered — handy if you need to claim GST (some niche FPV stores are not)

Are you looking to buy Ubiqiti Device Bridge Switch UDB-SWITCH [PC] in Australia?

Specifications

Dimensions: Device: 212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3")
WiFi Standard: WiFi 7
Spatial Streams: 4
Mounting Locations: Desktop, wall
Power Method: DC jack (54V DC/1.1A)
Power Supply: 54V DC/1.1A (Adapter included)
MIMO:
- 6GHz: 2x2
- 5GHz: 2x2
Max. Data Rate:
- 6GHz: 5.8 Gbps (BW320)
- 5GHz: 4.3 Gbps (BW240)
Antenna Gain:
- 6GHz: 8 dBi
- 5GHz: 8 dBi
Max. TX Power:
- 6GHz: 23 dBm
- 5GHz: 23 dBm
Max. Conducted TX Power: 26 dBm (Combined)
Supported Data Rates:
- 802.11be (WiFi 7): 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
- 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Security: WPA3 SAE (Always On)
Max. Power Consumption: 25W (Excluding PoE output)
Supported Voltage Range: 42.5–57V DC
Networking Interface: (1) 10 GbE RJ45 port (7) 2.5 GbE RJ45 ports
Antennas: (1) Internal antenna (1) RP-SMA connector for external omni-antenna
PoE Interface: (8) PoE+ ports
Max. PoE Wattage per Port: 30W
Total PoE Availability: 60W AC adapter input: 35W 210W AC adapter input: 185W
Antennas: (1) Internal
Management: Ethernet WiFi
Channel Bandwidth: 20/40/80/160/240/320 MHz
Weight: Device: Device: 548 g (1.21 lb) With mount: 563 g (1.24 lb)
Enclosure Material: Polycarbonate
Mount Material: Polycarbonate
LCM Display: 0.96" status display
Button: (1) Factory reset
NDAA Complaint: Yes
Certifications: CE, FCC, IC
Operating Frequency:
- Worldwide:
  5150—5875 MHz
  5945—7125 MHz
Ambient Operating Temperature: -30 to 40° C (-22 to 104° F)
Ambient Operating Humidity: 5 to 95% noncondensing
