Product description

Are you looking to buy HappyModel Mobula7 DJI O4 2S HD Micro FPV Whoop in Australia?

Introducing the Happymodel Mobula7 O4 micro FPV whoop! It comes with the new DJI O4 air unit which provides excellent and unbelievable FPV footage, the new Happymodel RS1102 KV10000 motor with HQPROP 45mm propellers, providing a powerful and smooth flying experience. This is a great whoop for indoor and backyard FPV flying.

Features

Equipment with New DJI O4 air unit
2S battery support Powerful and Smooth freestyle flying
UART ExpressLRS receiver support stable control link
Lighter and small for indoor FPV

Specifications

Motor
- Mode: RS1102 KV10000
- Configu-ration: 9N12P
- Stator Diamter: 11mm
- Stator Length: 2mm
- Shaft Diameter: Φ1.5mm
- Motor Dimension(Dia.*Len): Φ13.5mm*14mm
- Weight(g): 2.8g
- No.of Cells(Lipo): 1-2S
Propellers
- Weight: 0.25g
- Material: Poly Carbonate
- Pitch: 0.9
- Props Dia: 45mm
- Hub Thickness: 5mm
- Shaft: 1.5mm
Flight Controller
- MCU: STM32F405RGT6 (168MHZ, 1Mbyte FLASH)
- GYRO Sensor: BMI270 (SPI connection)
- Mount hole size: 25.5mm*25.5mm
- Power supply: 1-2S battery input (DC 2.9V-8.7V)
- Built-in 12A(each) Blheli_S 4in1 ESC
- Built-in Serial ExpressLRS 2.4G
- Built-in BMP280 Barometer
- Built-in 8MBp blackbox
- Built-in voltage meter sensor , voltage meter scale 110
- Built-in current meter sensor , current meter scale 470
Onboard 4in1 ESC
- Power supply: 1-2S LiPo/LiPo HV
- Current: 12A continuous peak 15A (3 seconds)
- Support BLHeli_S Bluejay firmware
- Factory firmware: Bluejay ESC V0.19
- Firmware target: Z-H-30
- Default protocol: DSHOT300
- When use 1s battery and high KV 0702/0802 motors, should set startup power to 1100/1200
Onboard UART ExpressLRS 2.4GHz Receiver
- Packet Rate option: 25Hz/50Hz/150Hz/250Hz/500Hz
- RF Frequency: 2.4GHz
- Antenna: enameled copper wire 31mm length
- Telemetry output Power: <12dBm
- Default firmware version: ExpressLRS V3.0.1
- Firmware target: HappyModel EP 2400 RX
- Could update firmware via ExpressLRS configurator
DJI O4 Air Unit
- Weight:
  - Air Unit (camera module excluded) - approx 5.1g
  - Air Unit (camera module included): Approx. 8.2 g
- Transmission Module: 30×30×6 mm (L×W×H)
- Camera Module: 13.44×12.36×16.50 mm (L×W×H)
- Camera Cable Length: 50mm
- Coaxial Cable: 50 mm
- 3-in-1 Cable: 50 mm
- Operating Frequency:
  - 5.170-5.250 GHz
  - 5.725-5.850 GHz
  - Operating frequency varies by region. Refer to local regulations.
- Transmitter Power (EIRP):
  - 5.1 GHz:
    - <23 dBm (CE)
  - 5.8 GHz:
    - <30 dBm (FCC)
    - <14 dBm (CE)
    - <30 dBm (SRRC)
- Live View Quality: 1080p at 30/50/60/100fps

Important Information

If you want to use DJI FPV Remote controller, please change betaflight settings like following picture,no need do any hardware modification to the flight controller:
