Are you looking to buy an iFlight Blitz Whoop AIO Board in Australia?

iFlight SKU: B012717
Firmware: IFLIGHT_BLITZ_F411RX
FW Version: 4.3.0

What if you could get the combined MCU speed and ESC power of a big stack, but carefully arranged on a 25x25 whoop size board? That would be crazy right? Well, iFlight just did it... This is the new iFlight BLITZ series AIO FC for your ultimate build. A future-proof all-in-one FC featuring an F411 flight controller, 5A ESC, 50mW VTX, and a built-in ELRS receiver. Lightweight, minimum size, minimum work.

Features

Support BLHeliSuite programmable
Built-in ELRS 2.4G CC2500 Receiver
5A continuous current
Super light only 4.8g
MCU：STM32F411
Power supply: 1S
Gyro: BMI270

iFlight BLITZ F4 V1 Whoop AIO Board F411 FC 5A 1S ESC ELRS 2.4Ghz RX

Specifications

Flight Controller

- Weight: 4.8g (with power cable, VTX, and VTX antenna)
- Mounting pattern: 25.5*25.5mm/φ3mm （half-hole)
- Supported Protocols: CC2500, SPI, D8, S-FHSS
- FC Firmware: IFLIGHT_F4SX1280
- BEC output: 5V 500mA
- Connector: Micro-USB
- MCU: STM32F411
- INA pad: n uart2
- Barometer: NO
- Size: 29*29mm
- Gyro: BMI270
- Blackbox: NO
- NOTE: F.PORT protocol RX input support, telemetry not supported.
ESC
- ESC // 5A
- Signal Support: Dshot, Oneshot, Multishot
- Current: 5A continuous and peak 6A
- ESC Firmware: O-H-30 BLS 16.8 (BlheliS) / Bluejay Q-H-50 (Bluejay)
- Current sensor: yes
- ESC Telemetry: NO
- Current scale: 400
- Input: 1S
VTX
- Protocol: Smart audio
- Power: PIT/25/50mW
- Connector: UFL/IPEX
- Input voltage: 5V
- Channels: 48CH
