iFlight SH CineFlow 6 O4 6S HD

Are you looking to buy iFlight SH CineFlow 6 O4 6S HD in Australia?

iFlight's new generation FPV drone, the 5-inch cinematic freestyle CineFlow 5, combines sleek design, easy maintenance, and a high-performance electronics system. Designed for immersive FPV experiences and professional video recording, CineFlow 5 delivers exceptional flight performance and cinematic-quality footage. Whether you're tackling freestyle tricks, high-speed pursuits, or long-range filming, CineFlow 5 is engineered to meet diverse flying needs with precision and reliability.

Features

• Innovative Frame Design, No Props in View: SH Series adopted an innovative frame design with no props in view while allowing flexibility for freestyle tricks. With balanced motor output, provides enhanced overall flight performance.
• Quick-release side panels: Quick-release side panels provide protection against debris and allow for easy maintenance while ensuring a cleaner setup with no cable entanglement.
• O4 Video Transmission, Enhanced Perception: SH Series is equipped with the latest DJI O4 Air Unit Pro, upgraded with 1.1/1.3-inch image sensor, it captures delicate details in low-light environments. With a 155° ultra-wide angle, capturing breathtaking visuals. Enjoy real-time video transmission with up to 1080p/100fps for an immersive flying experience.
• Down to 17% Hover Throttle: With powerful flight performance, CineFlow 5 can achieve a minimum takeoff throttle of 17%, and enhanced maneuverability for extreme high-speed chasing or acrobatic flights.
• High-performance Core Electronics System: Equipped with racing-grade BLITZ Mini F7 FC and BLITZ E55R 4-IN-1 ESC for high-intensity flight maneuvers. It features a larger MOS, and offers a 65A max burst current, which enhances stability and improves heat dissipation.
• Built-in high-precision GPS Module: The integrated high-precision GPS module with TPU cover prevents signal loss from external damage, reducing flyaway risks and enhancing device safety.
• Rear-mounted battery plug with anti-spark filter optimises weight distribution while increasing flight stability. Prevents circuit damage and enhances safety.
• Front-mounted Air Unit enhances cooling efficiency and minimises overheating risks, ensuring the air unit's stability and performance while extending its lifespan, no need to replace coaxial cable.
• Integrated action camera base mount, sleek and integrated design, redefines aesthetics.
• Strengthened the connection between the arm base and the drone to improve durability.

Specifications

• Product Name: CineFlow 5 O4 HD BNF
• Geometry: H-shaped
• FC: BLITZ Mini F7 Flight Controller
• ESC: BLITZ Mini E55R 4-IN-1 ESC
• Video Transmission: DJI O4 Air Unit Pro
• Frame wheelbase: 222mm
• Motor: XING2 2207 2050KV motors
• Prop: Nazgul F5 propellers
• Dimensions (L×W×H): 213*209*42mm
• Weight: 499±5g
• Takeoff Weight: Approx. 741±5g (With 6S 1400mAh Battery)
• Max Speed: 190 km/h
• Maximum Takeoff Altitude: 7000 m
• Max Hover Time: Approx. 12 min
• Max Flight Distance: 5 km
• Operating Temperature Range: -20° to 40° C
• Antennas: Dual Antennas
• GNSS： GPS+SBAS+Galileo+QZSS+Glonass

Video Transmission

• Product Name: DJI O4 Air Unit Pro
• Image Sensor: 1/1.3-inch
• Lens: FOV: 155°
• ISO: 100-25600
• Video Resolution: 1080p/100fps H.265
• Video Format: MP4, Max Video Bitrate: 130Mbps
• Colour Mode: Normal Mode/D-Log M
• Stabilisation: RockSteady 3.0+ ; Stabilisation function off (When RockSteady is enabled, the shooting angle only supports standard.)
• Live View Quality: 1080P@100fps
• Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz
• Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))
• Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
• Communication Bandwidth: Max 60 MHz
• Antenna: Dual antennas
• Built-in Storage: 4GB
• Supported SD cards: microSD (up to 512GB)
• Operating Temperature: -10° to 40° C
• Weight: Air Unit (camera module included): Approx. 32 g
• Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

Includes

• 1 x SH CineFlow 5 O4 6S HD BNF
• 2 x Antennas
• 1 x Battery pad
• 2 x propeller(Pairs)
• 2 x Battery strap
