Are You Looking For SpeedyBee F405 WING MINI Fixed Wing Flight Controller In Australia?
Specifications
-
SpeedyBee F405 Wing Mini FC Board
- MCU STM32F405, 168MHz, 1MB Flash
- IMU(Gyro&Accelerometer) ICM-42688-P
- Barometer SPL006-001
- OSD Chip AT7456E
- Blackbox MicroSD Card Slot
- UART 6 sets (USART1, USART2, USART3, UART4, UART5,
- UART6 - Dedicated for Wireless board Telemetry connection)
- I2C 1x Used for magnetometer, digital airspeed sensor
- ADC 4x (VBAT, Current, Analog RSSI, Analog AirSpeed)
- PWM 12x (9x pin headers + 2x solder pads + 1x "LED" pad)
- ELRS/CRSF Receiver Supported, connected to UART1
- SBUS Built-in inverter for SBUS input (UART2-RX)
- LED 3x LEDs for FC STATUS (Blue, Green) and 3.3V indicator (Red)
- Analog RSSI Supported, Named as "RS"
-
Dual Analog Camera Switching Default to Camera1 Video Input (C1). Switch between C1 and C2 using ArduPilot Relay or INAV Modes/USER.
- Both cameras should have the same video format, either PAL or NTSC.
- Supported FC Firmware INAV: SpeedyBeeF405WING (default)
- ArduPilot: SpeedyBeeF405WING
- Weight 5.6g
- MCU STM32F405, 168MHz, 1MB Flash
-
SpeedyBee F405 Wing Mini PDB Board
- Input voltage range 7~26V (2~6S LiPo)
- Battery Voltage Sensor Connect to FC board VBAT, 1K:10K (Scale 1100 in INAV, BATT_VOLT_MULT 11.0 in ArduPilot)
- Battery Current Sensor 80A continuous, 150A peak Connect to FC board Current (Scale 195 in INAV, 50 A/V in ArduPilot)
- TVS Protective diode Yes
- FC BEC output Output 5.2V +/- 0.1V DC Continuous current 2 Amps, 3A Peak Designed for FC, Receiver, GPS module, AirSpeed Sensor, Telemetry module
- VTX & Camera power supply The VTX power interface Vv offers two power supply options: direct battery voltage or integrated BEC 5V (sharing the 5V4A Servo BEC voltage)
- By default, it is set to battery voltage (Ensure the VTX and camera input voltage range is compatible)
- Switching to 5V power supply is possible via pad jumper (using Servo BEC output)
(If using this method, ensure the current requirements for both servo and VTX are sufficient) - Servo BEC output Output 5V +/- 0.1V DC Continuous current 4 Amps, 5A Peak Voltage adjustable, 5V Default, 6V via jumper Designed for Servos.
- Weight 5.5g
- Input voltage range 7~26V (2~6S LiPo)
-
SpeedyBee F405 Wing Mini Wireless USB Extender
- Wireless Configuration (long press BOOT button for 6 seconds to switch modes)
- INAV:Please make sure the MSP switch on UART 6 is turned on and set to a baud rate of 115200 ArduPilot:Please make sure the Serial 6 is set to baud rate 115200 and protocol Mavlink2 BLE mode, connect to Speedybee APP
-
Wi-Fi (AP)mode, able to connect to Speedybee APP, QGroundControl APP, MissionPlanner, etc. WiFi: Speedybee eFLY-WIFI Password: 88888888
- Wi-Fi (STA)mode, able to connect to QGroundControl APP, MissionPlanner, etc.
- Step 1: turn on Personal Hotspot;
- Step 2: Set hotspot, locate NAME/Device Name/Hotspot name/etc.
- Step 3: change the current name to eFLY and the password is, 88888888
- Wireless off mode
- USB Port Type Type-C
- Buzzer 5V Active Buzzer
- Weight 3.2g
- Wireless Configuration (long press BOOT button for 6 seconds to switch modes)
