Are you looking to buy T-Hobby F7 Pro V2 Full Function 30x30 ICM42688-P Flight Controller with Wifi & Bluetooth in Australia?
The T-MOTOR T-HOBBY F7 PRO is a full-featured 30.5×30.5mm FPV flight controller designed for freestyle, cinematic and advanced FPV builds.
Built-in WiFi and Bluetooth enable wireless Betaflight tuning, firmware updates, motor direction settings and Blackbox analysis. With 8 UARTs, up to 8 PWM outputs, DJI Air Unit support, Betaflight and INAV compatibility, the F7 PRO provides flexible connectivity for complex FPV builds.
Key Features
- Built-in WiFi & Bluetooth
- Wireless Betaflight tuning & firmware updates
- Wireless Blackbox data analysis
- 8 UARTs & up to 8 PWM outputs
- Supports Betaflight & INAV
- DJI Air Unit plug-and-play support
- SpeedyBee App compatible
- 30.5 × 30.5mm mounting pattern
- VTX remote control support
Specifications
| Specification | Details |
|---|---|
| Model | F7 PRO |
| MCU | STM32F722 |
| Gyro | ICM42688P |
| Barometer | BMP280 |
| Firmware | Betaflight / INAV |
| Wireless | WiFi + Bluetooth |
| UART | 8 |
| PWM Outputs | Up to 8 |
| Mounting Pattern | 30.5 × 30.5mm |
| DJI Air Unit | Supported |
| Blackbox | Supported |
| VTX Remote Control | Supported |
Recommended For
Ideal for freestyle, cinematic and advanced FPV drones that require multiple peripherals, wireless configuration and flexible flight-control options.
The 8 PWM outputs and INAV support also make the F7 PRO suitable for more complex multirotor configurations.
Compatibility
Supports:
- DJI FPV Air Unit
- Analog FPV systems
- Betaflight
- INAV
- SpeedyBee App
- GPS
- External barometer
- VTX remote control
FAQ
Does the F7 PRO support wireless Betaflight configuration?
Yes. Built-in WiFi and Bluetooth allow wireless Betaflight tuning, firmware updates and other configuration functions.
Does it support DJI FPV?
Yes. The F7 PRO supports direct connection with the DJI FPV Air Unit.
Does the F7 PRO support INAV?
Yes. It supports both Betaflight and INAV firmware.
What mounting size does it use?
The F7 PRO uses the standard 30.5 × 30.5mm mounting patter
