TBS Mojito Servo 2pc

TBS Mojito Servo 2pc

$69.95 AUD
Skip to product information
TBS Mojito Servo 2pc
  • TBS Mojito Servo 2pc
  • TBS Mojito Servo 2pc
  • TBS Mojito Servo 2pc
TBS Mojito Servo 2pc

TBS Mojito Servo 2pc

$69.95 AUD
GST included Shipping calculated at checkout.

Delivery options

TBS Mojito Servo 2pc

Pickup

Local pickup is free. Collect from Somersby NSW; choose Pick up at checkout instead of a courier. We open 7:30am Monday - weekend orders are usually ready to collect by 10am.

Delivery options
3 In stock
Price match

Request a price match

TBS Mojito Servo 2pc Our price: $69.95

We reply approved or declined by email, usually within 15–60 minutes during business hours. Matching is at our discretion — we can't promise every price, but if it's fair we usually will.
Order in H, M, Seconds (before 1pm Sydney time) for same day despatch.
Fast dispatch from Somersby, NSW Easy returns Australian warranty & local support

Pickup available

1/80 Somersby falls RD, Somersby NSW
We open 7:30am Monday - weekend orders are usually ready to collect by 10am
Product details
SKU: 31803
Shipping Weight: 40g
W/H: W-03-B-10
Categories: FPV Wing Servos, TBS Mojito Collection: Your Ultimate FPV Wing Kit and Accessories, TBS Team Black Sheep
Tags: Servos, TBS, TBS Mojito


Are you looking to buy TBS Mojito Servo 2pc in Australia?

The perfect companion for your TBS Mojito, the Mojito Servo is custom-designed to enhance the performance of this advanced flying platform. Built to withstand the rigors of high-speed flights, it ensures your maneuvers are as aggressive and precise as you desire. Experience smooth, exhilarating control that complements the Mojito’s capabilities, allowing you to navigate the skies with confidence and finesse.

Specification

  • Operating Voltage: 4.8V-6V DC
  • Standby Current: ≤20 mA
  • Consumption Current* (No Load): 4.8V ≦70 mA / 6V ≦80 mA
  • Stall Current: 4.8V ≦1.1 A / 6V ≦1.3 A
  • Rated Torque: 4.8V ≥2.8kgf·cm / 6V ≥3.2kgf·cm
  • Max. Torque*: 4.8V ≥4.5 kgf.cm / 6V ≥5.5 kgf.cm
  • No Load Speed*: 4.8V ≦ 0.26sec/60° | 6V ≦ 0.24sec/60°
  • Rotating Direction: CCW（500→2500us）
  • Pulse Width Range:500~2500us
  • Neutral Position: 1500us
  • Operating Travel Angle: 90° ±10° (1000~2000 us)
  • Max. Operating Travel Angle: 180°±10°（500~2500us）
  • Mechanical Limit Angle: 360°
  • Left & Right Travelling Angle Deviation: ≤ 6°
  • Centering deviation: ≤ 1°
  • Back Lash*: ≤ 1°
  • Dead Band Width: ≤ 5 us
  • Operating Temperature Range: -10℃～+50℃
  • Storage Temperature Range: -20℃~+60℃
  • Operating Humidity Range: ≤ 90%RH
  • Storage Humidity Range: ≤ 90%RH
  • Weight: 21± 0.5g
  • Case Material: ABS
  • Gear Set Material: Metal
  • Reduction ratio: 1/403
  • Motor Type: Core motor
  • VR Parameter
    • Type: Carbon-Film Potentiometer
    • Angle: 330°
    • Life: 1,000,000 Cycles Min
  • Cable:
    • Material: Ф1.08,19 芯 PVC
    • Length: 115±5mm
  • Horn Gear Spline: 25T/Φ5.9mm
  • Horn Gear Type: Please check product photos
  • Rocker Arm Screw: WPMФ2.5* 5 W=5 镀镍
  • Connector:
    • Type: JR/3Pin/2.54mm
    • Pin Assignment
      • Brown: GND
      • Red: Vcc
      • Orange: Signal / PWM
  • Communication Interface: PWM
    • Signal Voltage: V (HIGH: Min,2.0V, Max.Vcc) / (LOW: Min,0.0V, Max.0.45V)
    • Frame Rate: T (3.0～30ms (Default 20ms))
    • Left/Center/Right: Td (2500/1500/500us)
  • Amplifier Type: Digital
