Are you looking to buy TRUERC X²-AIR 2.4Ghz Antenna in Australia?
By pairing two of our famous X-AIR you get more gain AND wider beam! Of course, there’s a compromise which is reduced vertical beam width, but good FPV don’t happen up high! A novel approach was taken to match the two antennas together and
Specs
- Frequencies: 2.3-2.5GHz
- Gain: 13 dBic
- Axial Ratio: 1 (perfect)
- Beam-width Horizontal*: 150deg
- Beam-width Vertical*: 62deg
- Hor. beam @-3dB**: 74deg.
- Vert. beam @-3dB**: 34deg.
- Connector: SMA
- Dimension: 10.2″x5.2″x3″ (SMA cable length of 1.2″)
*Coverage where reception is at least equivalent to an
**Coverage where at least 70% of the max range is obtained.
