Are you looking to buy TBS Lucid H7 Wing FC in Australia?

For seasoned wing pilots, affordable high quality flight controllers have been far and between. Shortcomings in either supported software, redundancy on hardware, or price, have made it hard to pick a clear contender for your next project.

Introducing the TBS Lucid H7 Wing FC. Full-featured, versatile, reliable, and affordable. Behold! Our giant list of specs:

Specifications

MCU: STM32H743VIH6, 480MHz, 2MB Flash
Input voltage: 8V-50.4V (3-12S)
Output power: 8A cont./10A peak BEC. 5V, 6V, 8.4V (selectable)
Channels: 13x PWM (including LED)
Gyro: ICM42688 x 2 (SPI1 & SPI4)
Baro: DPS310 (I2C2)
Peripherals: 7x UART, 2x I2C, 1x CAN
Measurements: 6x ADC (Vbat, Current, CB2, CU2, RSSI, AirSpeed)
High speed ports: MicroSD BlackBox, SPI3 on pin headers
Analogue FPV: Switchable dual camera inputs, AT7456E OSD, 5V/9V/12V support at 5A (selectable)
Digital FPV: "DJI"-connector with SBUS and OSD communication
Current sensor: 165A cont. / 240A peak
FC BEC: 5V 3A cont. (for FC&peripherals)
FPV BEC: 9V/12V 5A (selectable)
Dimensions: 54 x 36 x 13 mm

Tech Details

Battery Voltage Sensor: 1K:20K (Scale 2100 in INAV, BATT_VOLT_MULT 21.0 in ArduPilot)
ADC VB2 voltage divider: 1K:20K
ADC AirSpeed voltage divider: 20K:20K
ArduPilot Target: TBS_LUCID_H7_WING
INAV Target: TBA
Betaflight Target: TBA
